A high activity granular Activated Carbon manufactured by steam activation from select coconut shell charcoal. Its enhanced micro porosity makes it particularly well suited for the removal of low molecular weight organic compounds and their chlorinated by-products such as chloroform and other
trihalomethanes (THM’s). It is also ideally suited for the removal of oxidizing agents such as chlorine and ozone from process water. An important feature of this material is its superior mechanical hardness and the extensive dedusting during its manufacture that ensures an exceptionally clean activated carbon product.
NSF / ANSI Standard 61
NSF/ANSI 42
A catalytic, high activity granular activated carbon manufactured by steam activation of selectcoconut shell charcoal. The catalytic activity of this activated carbon makes it highly effective for the removal of chloramines and hydrogen sulfide from potable water. Its large micropore volume makes it particularly well suited for the removal of low molecular weight organic
compounds and their chlorinated by-products such as chloro- form and other
trihalomethanes (THMs). An important feature of this material is its supe- rior
mechanical hardness and the extensive dedusting during its manufacture ensures an exceptionally clean activated carbon product.
An activated carbon
with a catalytic activity
that is required for
liquid phase application
involvingoxidation, reduction, and decomposition.
Garnet is a high hardness, high density granular filter
media. It is normally used as the lower (final) filtration in
a multi-media bed down flow filtration system. Called
multi-media or mixed media filtration, the high density,
small grain size of Garnet solves a major filtration
problems. In a single media granular filter such as a sand
filter, the material will hydraulically classify during
backwash according to granule size, the smallest rising to
the top. When water flows downward through the sand,
the fine particles at the top of the bed do most of the
straining of the sediment. The penetration of the solids
into the entire bed allows for increased solids storage,
longer filter runs, and higher filtration rates.
Garnet meets AWWA B100-96 specifications.
Garnet mineral sand is classified by Under-writers Laboratories Inc.®
In Accordance with Standard ANSI/NSF 61
Garnet mineral sand manufactured by Interna-
tional Garnet Co., Inc. is classified by Under-
writers Laboratories Inc.® in Accordance with Standard
ANSI/NSF 61
KDF® Process Media delivers unmatched advantages for water filtration and purification systems. As a trusted
supplier to the industry’s top OEMs and filter manufacturers, KDF®’s unique redox-based filtration, broad
contaminant removal capability, microbial control, and durability make it stand out from conventional filtration
technologies.
Redox (Oxidation-Reduction) Reaction: KDF® Process Media operate on the principle of redox reactions, where
electrons are transferred between molecules. This process changes harmful contaminants into harmless
components. For example, KDF® can convert chlorine into chloride, which is less reactive and non-toxic.
Broad Spectrum of Contaminant Removal: Unlike traditional carbon filters that primarily target organic
compounds and chlorine, KDF® Process Media can remove a wide range of contaminants, including heavy metals
(like lead, mercury, and nickel), chlorine, hydrogen sulfide, and even control microbial growth.
Enhanced System Performance and Longevity: KDF® Process Media significantly improve the efficiency of existing
carbon-based systems by extending their lifespan, reducing maintenance needs, and lowering total operating
costs.
Effective Microorganism Control: Our innovative media creates an environment that eliminates harmful
microorganisms and disrupts the functioning of others, providing robust protection against microbial
contamination and preventing biofouling without the need for chemical disinfectants.
High-Temperature Tolerance: KDF® Process Media can operate effectively in high-temperature environments,
where other filtration materials like carbon may degrade. This makes it suitable for industrial and hot water
applications, including showerhead filters.
Environmental Benefits: Being a recyclable material made from high-purity copper and zinc, KDF® Process Media
have a lower environmental impact compared to disposable filter cartridges commonly used in other
technologies.
Compatibility with Other Technologies: KDF® Process Media are often used in combination with other filtration
systems, such as carbon filters or reverse osmosis units, enhancing their efficiency and lifespan by pre-treating
the water and reducing the load on subsequent stages.
KDF® 55 Process Medium
Designed specifically for removing or reducing chlorine and
water-soluble heavy metals. It controls scale, bacteria and
algae, even in hot water. The process medium received NSF
International Certification and is certified by NSF to NSF/ANSI
Standard 42 – Drinking Water Treatment Units – Aesthetic
Effects. This medium is also in compliance with California’s
Health and Safety Code Section 166875 (or commonly know as
AB1953) and Vermont Act 193.
Certified to NSF/ANSI/CAN 61, which now includes NSF/ANSI/CAN 372 Lead Free requirements, rapid sand is a
remarkable advance in media filtration technology. Based on a rare natural mineral that is highly processed and refined,
rapid sand’s unique properties allow it to radically alter the performance and cost of media filtration. The hardness, stability
and micro-porous character of sapid sand makes it a perfect filtration media for virtually every application in the water and
wastewater treatment industry.
High Filtration Performance: 3-5 Micron Removal
High-Capacity Filtration Throughout Bed: >2x The Capacity Of Multimedia Filtration
High Service Flow: 3-4 Times That Of Multimedia With Superior Filtration
Long Lasting Media: >5 Years (Not Consumed In The Process)
Simple, Periodic Backwash Required: Keeps The Media Clean & Operating Efficiently
Made from high purity clinoptilolite, which delivers superior performance over conventional filter sands or multimedia, and at a lower cost. The material is mined in western USA and then highly processed and graded; the resulting product is hard and stable with a high surface area and micro-porous character in addition to surface micro-crystals making it an ideal filter media.
Rapid sand has high filtration performance at <5 micron compared to 12 to 15 micron for multimedia. It also has a higher flow capacity, typically three to four times that of multimedia. This higher flow rate means a greater performance can be achieved from existing vessels when upgraded with Next-Sand, or for new applications smaller filter vessels would be required to achieve the same results.
Filtration through the entire media bed depth provides more than twice the capacity of multimedia filtration. It has a higher dirt holding capacity so requires less frequent backwashing, leading to reduced downtime. Lighter weight and lower volume
requirement means lower capital and shipping costs than multimedia and the product also lasts longer. The media isn’t consumed in the filtration process; a simple periodic backwash will keep the media clean and operating efficiently for five years or more.
Physical properties as follows:
Composition: High-Purity Alumino-Silicate (Clinoptilolite)
Size: 0.4-1.4mm (Approx 14×40 mesh)
Color: Dark Grey
Surface Area: 25m2/gram
Surface Absorption: Hydrophilic
Thermal Stability: Stable up to 500 ̊C
Coeffficient of Uniformity: 1.7
Bed Void Volume: 55%
Surface Charge: Net Negative
Bio-Ceramics is the most efficient way to upgrade your water anywhere anytime. It is made of natural
mineral stone powder, efficiently making healthy water, such as alkaline water, antioxidant ORP water,
mineral water, and activated small water. Antibacterial and dichlorination are also efficient.
Calcium Alkaline Bio Ceramic adopts the latest technology and mineral materials such as natural shells. It
is a new type of alkaline mineral with the latest “micro porous sustained release” technology and high
temperature roasting process. It has long service life, safe and controllable and low price. By increasing
the concentration of Ca+ in the water, the balls have very good capability to increase pH with the level 7-
11 to create alkaline potable water as your require. With liquid status, the calcium is easy to be absorbed
by human bodies. The ball can be applied to water purifier filters, net kettles and alkaline products.
Alkaline Calcium Ball: Alkaline correction: pH 7.0 – 9.0+
Mineral release: K, Ca, Na, Mg
Far-infrared Ball: Far-infrared wavelengths: 7-15um
Tourmaline Ceramic Ball: Mineral release: H2SiO3, K, Ca, Na, Mg, Zn, Se, Sr
Alkaline correction: 7.5-7.8 pH
Maifan Ball: Mineral release: K, Ca, Na, Mg, Zn, Fe
Negative Ion Ball: Negative ion release: 1000-3000cm3
